JPR-CT3408 Seawater Pump

  • JPR-CT3408 Seawater Pump

Write a review

Note: HTML is not translated!
    Bad           Good
  • Brand: JMP Corporation

  • Description

    Caterpillar Replacement Pump

    **Parts Only**



    Impeller: IMP002602



    Engine model 3408



    Cross reference no.:

    Caterpillar 3N7714 / OR7723 / OR7553

    Gilkes 44943-006



    Serviceable items

    S/N Part Number Caterpillar Description Qty.
    1 BER0024 2L5271 Ball Bearing 1
    2 BER0057 2H3829 Ball Bearing 1
    3 BOL0157 5P8026 Pin-Cotter 1
    4 IMP002602 3N8214 Bronze Impeller 1
    5 KEY0022 1487992 Key 1
    6* MCSSET0010 5N6054 Mechanical Seal Set 1
    7* ORG002901 3N8201 O-Ring 1
    8 PORT002 5N4503 Plate Port 2
    9* RET0023 5N2903 Oil Seal 1
    10 RIG0003 3N8213 Distance Ring 1
    11 SHA0047 3N8203 Shaft 1
    12 SNP0014 4L9020 Snap Ring 1
    13* SPC0004 3N8211 Spacer 1




    *Sold Separately*

    Seal Kit: JMK0003

    Repair Kit: To Be Advise (TBA)



  • Product Code: JPR-CT3408
  • Availability: In Stock
